2025 Masaba 36x150
Key Specs
Unit OVerview
* 2025 Masaba 36x150 Telestacker | Heavy-Duty Portable Stacking Conveyor for High Output * Elec: 480V /60HZ * Tubular Undercarriage * Tandem Axle walking beam * Hydraulic Radial Travel Folding Axle * Hydraulic Raise & Lower with 20HP unit * Hydraulic Landing Legs * Power Travel - 4 wheel planetary drive * On-board counterweight * Masaba Track Technology * 6’ Hopper with adjustable rubber flashing * 5th wheel hitch, brakes, lights and mud flaps * Tail end lifting eyes * Anchor pivot plate * Tail anchor plate * Remote Grease Bank * Appropriate Guarding
additional information
features
» Drives - Class II head end
» WEG 40 HP
» Dodge TAII reducers
» 1,000 TPH based on 100# per cu/ft at 18O
» 400/600 FPM belt speed
» 3 ply belting
» Flexco belt scraper
» CEMA C Idlers, Heavy Duty Pulleys
SPECS
- Engine
- WEG 40 HP
- Equipment Type
- Stackers, Conveyors, and Feeders
